Product Details
Product Name: Cast Steel Ball Valve
Product Standard: BS 5351/API 6D
Type of Pattern: Straight Type
Pressure/Class/Rating: Class 150
Construction Materials
Body Material: CCS ASTM A216 Gr. WCB
Trim: Stem - S.S. ASTM A276 Type 410
Ball: ASTM A351 Gr. CF8/AISI-304
Seat Ring & Gland Packing: Included
Design Features
Design: Three Piece Design
Operation: Lever Operated
Seat Type: Renewable seat
End Details: Flanges as per ANSI B 16.5 Class 150 R.F. Undrilled
Testing & Certification
Body Test Pressure: 30 Bar g (435 Psig) Hydraulic
Seat Test Pressure: 22 Bar g (320 Psig) Hydraulic & 6.9 Bar g (100 Psig)
Maximum Working Temperature: 250°C
Certification: Test Certificate in Form II-C as per IBR furnished with every supply
Applications
Water
Oil
Gas
Steam
