Tube Types
Round
Square
Rectangle
Hydraulic
U-Tube
Coil Form
Test Certifications
Manufacturer Test Certification
EN 10204 3.1 & 3.2
NACE MR0175
Stainless Steel & Duplex Steel Tube Specifications
| Parameter | Details |
|---|---|
| Size Range | 6mm OD to 219.08mm OD |
| Thickness Range | 0.4mm - 12.7mm |
| Type | Standard length & Cut length |
| Stainless Steel Grades | ASTM/ASME A213, A249, A269 - TP 304/304H/304L, 316/316H/316L/316Ti, TP 309, 310, 317L, 321, 347, 904L, 254SMO |
| Duplex Steel Grades | ASTM A789 - UNS S31803, S32750, S32760, S32205 |
Alloy Steel, Carbon Steel & LTCS Tube Specifications
| Parameter | Details |
|---|---|
| Size Range | 6mm OD to 219.08mm OD |
| Thickness Range | 0.4mm - 12.7mm |
| Low Alloy Steel Grades | ASTM A213 - T-1, T-2, T-5, T-9, T-11, T-12, T-22, T-91 etc. |
| Carbon Steel Grades | BS 3059 Gr. 360/440, SA 179, SA/ASTM A210 Gr. A1 |
Copper & Nickel Alloys Tube Specifications
| Parameter | Details |
|---|---|
| Size Range | 6mm OD to 219.08mm OD |
| Thickness Range | 0.4mm - 12.7mm |
| Admiralty Brass Grades | ASTM B111 - C44300, C44400, C44500, C68700 |
| Copper Nickel Grades | ASTM B111 - C70600 (90:10), C71500 (70:30), C71640 |
| Nickel Alloy Grades | Nickel, Monel, Inconel, Alloy 20, Hastelloy, Titanium |
| Specialized Tubes | Capillary Tube, IBR Tubes, Copper Nickel Tube |
Key Features
Comprehensive Material Options: Includes stainless, duplex, alloy/carbon steels, and non-ferrous alloys
Precise Dimensional Range: 6mm to 219.08mm OD with 0.4mm-12.7mm thickness options
Multiple Standards Compliance: ASTM, ASME, BS, EN, NACE
Specialized Variants: U-Tubes, Coil Forms, Capillary Tubes available
Certified Quality: EN 10204 and NACE MR0175 certified products
