WNRF

Weldneck Flange

This type of flanges is attached to the pipe bybutt welding, mostly these flanges are used forcritical services. So these flanges are suitable forhandling extreme pressure and temperature andbecause of this feature, these flanges are mostlyused for petrochemical and refinery plants. Thebores of both the pipe and flange match and thiswould reduce the turbulence and erosion insidethe pipeline. The weld neck flanges are bored tothe ID of the pipe and it has a high neck intowhich the pipe is welded. This flange isconsidered the best welding flange due to itshigh, heavy neck.

Grades

ASTM A182/182M ASME SA182/182M | F 304, F304L, F304H, F310, F316, 316L, F316H, F347, F347H, F317, F317L, F321, F321H, F316TI, F347 , F347H, F51, F60, F53,C276,C22,MONEL 400,INCONEL 625,INCONEL 825,TITANIAUM AND ETC.

JIS G3214 | SUS F304, SUS F304L, SUS F304H, SUS F316, SUS F316L, SUS F316H, SUS F347, SUS F347H, SUS F317, SUS F317L, SUS F321, SUS F321H

DIN 10222-5 | 1.4301, 1.4306, 1.4307, 1.4541, 1.4571, 1.4401, 1.4404, 1.4410, 1.4438, 1.4450, 1.4462
